Description
| Code | Spiral | HOSE BORE | DIMENSIONS | |||
|---|---|---|---|---|---|---|
| PART NO. | THREAD T | Nominal inner diameter DN | Designator DASH | L | S1 | S2 |
|
22611D-04-04SM
|
G1/4”X19
|
6
|
04
|
23
|
14
|
19
|
|
22611D-06-06SM
|
G3/8”X19
|
10
|
06
|
25
|
17
|
22
|
|
22611D-08-08SM
|
G1/2”X14
|
13
|
08
|
28.5
|
22
|
27
|
|
22611D-10-08SM
|
G5/8”X14
|
13
|
08
|
30
|
22
|
30
|
|
22611D-12-10SM
|
G3/4”X14
|
13
|
08
|
31.5
|
27
|
32
|
|
22611D-12-12SM
|
G3/4”X14
|
19
|
12
|
32.5
|
27
|
32
|
|
22611D-16-16SM
|
G1”X11
|
25
|
16
|
36.3
|
32
|
41
|
|
22611D-20-20SM
|
G1.1/4”X11
|
32
|
20
|
41.5
|
41
|
50
|
Stainless Steel Hose Fitting Bsp 1 4 Male Hydraulic Fittings Size Chart Note: 1. The above code is used for braided hoses. 2. If it needs to be used for winding hose, the code is changed to 22612D-XX-XXSM.
NOTE:1.For use with braided hoses.2.If use spiral hoses, hose fitting series number is 22612D-XX-XXSM.
